418 kWh
CORE
3-layer
Unbalanced Load Support
Intelligent
Liquid Cooling
BMS + EMS
Integrated
Real-Time
Remote Monitoring
Air-Cooled Energy Storage System
Higher capacity on the same engineering platform. Designed for larger commercial and industrial loads - data centres running at scale, manufacturing plants with continuous shift operations, hospital campuses where stored energy is also emergency infrastructure. At this capacity, the financial case is direct: the stored energy pays for the system within a predictable number of billing cycles. The decision is not whether to invest. It is when.
DC Side
418 - 40
418 - 69
418 - 80
Cell Type
LFP / 314 Ah
Pack Configuration
52.248 kWh / 1P52S
System Configuration
418 kWh / 1P416S
Rated DC Voltage
1331.2 V
DC Voltage Range
1164.8 ~ 1497.6 V
Max. Charge/Discharge Rate
0.25 P
0.5 P
0.5 P
Max. Depth of Discharge
100% (25 ± 2°C)
AC Side
418 - 40
418 - 69
418 - 80
Rated Output Power
100 kW
215 kW
210 kW
Rated AC Voltage
400 V
690 V
800 V
AC Voltage Range
-15% ~ +10%
Grid Type
3W + PE
Rated Frequency
50 Hz / 60 Hz
Power Factor
0.99 / -1 ~ +1
THDi
≤ 3%
DC Ratio
< 0.5% Ipn
General
418 - 40
418 - 69
418 - 80
Max. Round Trip Efficiency
89%
Cycle Life
≥ 8,000 cycles
Communication
Modbus TCP/IP
Fire Suppression System
Aerosol
Ingress Rating
IP55
Cooling
Liquid cooling + Forced air cooling
Operating Temperature
-25°C ~ 55°C (Derating after 45°C)
Anticorrosion Rating
C4 (C5 optional)
Humidity
0 ~ 95% RH (non-condensing)
Noise
≤ 80 dB
Altitude
3000 m (Derating above 2000 m)
Dimensions (W*D*H)
1,500*1,350*2,400 mm
Weight
3,800 kg
